Coil Nails
The Essential Fasteners for Wooden Packaging
Coil Nails are the backbone of secure and efficient fastening for a wide array of applications, including wooden cable drums, pallets, boxes, and more. Designed for use with a pneumatic nailer, commonly referred to as a coil nailer, these nails offer unbeatable convenience and speed.
Our Coil Nails come in a versatile range, with diameters spanning from 2.1 mm to 3.4 mm and lengths ranging from 25 mm to 125 mm. Crafted for durability, they feature a protective varnish coating, guarding against rust and humid conditions.
Choose the right shank for your needs – whether it’s the smooth Shank, the robust Screw Shank, or the gripping Ring Shank. Elevate your fastening projects with Coil Nails, the trusted choice for professionals who demand reliability and precision in their work.”
TECHNICAL SPECIFICATION
| Serial | Shank Dia meter | Shank Length | Nails Per Coil | Coils per Carton | Nails per Carton |
|---|---|---|---|---|---|
|
1 |
2.1 mm |
25 mm |
350 |
48 |
16800 |
|
2 |
2.1 mm |
32 mm |
350 |
48 |
16800 |
|
3 |
2.1 mm |
38 mm |
350 |
48 |
16800 |
|
4 |
2.1 mm |
45 mm |
350 |
48 |
16800 |
|
5 |
2.3 mm |
45 mm |
300 |
48 |
14400 |
|
6 |
2.3 mm |
50 mm |
300 |
36 |
10800 |
|
7 |
2.3 mm |
56 mm |
300 |
36 |
10800 |
|
8 |
2.5 mm |
50 mm |
300 |
36 |
10800 |
|
9 |
2.5 mm |
56 mm |
300 |
36 |
10800 |
|
10 |
2.5 mm |
60 mm |
300 |
36 |
10800 |
|
11 |
2.5 mm |
65 mm |
300 |
24 |
7200 |
|
12 |
2.5 mm |
70 mm |
250 |
24 |
6000 |
|
13 |
2.8 mm |
70 mm |
250 |
24 |
6000 |
|
14 |
2.8 mm |
75 mm |
250 |
24 |
6000 |
|
15 |
2.8 mm |
80 mm |
250 |
24 |
6000 |
|
16 |
2.8 mm |
90 mm |
250 |
24 |
6000 |
|
17 |
3.0 mm |
100 mm |
150 |
12 |
1800 |
|
18 |
3.4 mm |
100 mm |
150 |
12 |
1800 |
| Packaging | |
|---|---|
|
5 ply paper corrugated box packaging with 5 mm thickness. |
|
|
Plastic pipe fitting within the coil for safety. |
|
15 DEGREE WIRE COLLATED COIL NAILS (FASTENERS)
| Nail Technical Specification | |
|---|---|
|
Head Diameter |
5.5mm to 7.5mm |
|
Head Thickness |
0.9mm to 1.10mm |
|
Head Type |
Flat and plain |
|
Shank Type |
Smooth - Ring - Screw |
|
Diameter |
2.1mm to 3.4mm |
|
Length |
25mm to 100mm |
|
Point |
Diamond cut |
|
Material |
SAE1008 Low Carbon Steel |
|
Melting Point/Freezing Point |
> 2500°F (Steel) S |
Disclaimer of Expressed and Implied Warranties
The information in this document is believed to be correct as of the date issued. However, no warranty of merchantability, fitness for any particular purpose, or any other warranty is expressed or is to be implied regarding the accuracy or completeness of this information, the results to be obtained from the use of this information or the product, the safety of this product, or the hazards related to its use. This information and product are furnished on the condition that the person receiving them shall make his own determination as to the suitability of the product for his particular purpose and on the condition that he assumes the risk of his use thereof. Packing and Specifications may change if required in future as per company policies.
| Wire collated coil nail specification | ||
|---|---|---|
|
Degree |
15 degree collated |
|
|
Welding Wire |
Copper Coated Steel Wire |
|
|
1st Welding Point |
2.1mm |
7.5mm to 8.5mm |
|
2.3mm to 3.1mm |
18.50mm to 19.50mm |
|
|
2nd Welding Point |
2.1mm |
18.50mm to 19.50mm |
|
2.3mm to 3.1mm |
36.50mm to 37.50mm |
|
|
Application |
Wooden Pallets Fastening Wooden Cable Drum Fastening Wooden Crates and boxes fastening |
|
|
Colour |
Synthetic & Petroleum Binder Anti Corrosive yellow Coating. |
|
|
Coating |
10 to 20 Micron yellow coating. Anti Corrosive for 3 Months. If Stored in non-humid dry atmosphere. |
|
- Store in dry place to maintain product integrity.
- Wear safety glasses when used with installation tools. Provide first-aid supplies for significant contact injuries
Disclaimer:
The Product Specifications mentioned above are for information purpose only. However no guaranty or warranty of the material sustainability or accuracy can be claimed. The life of material depends on weather conditions, user’s skills & varies as per applications.
